14
Charging the battery
1. Plug the small plug of the power line adapter into the socket underneath the battery.
2. Now plug the power plug of the power line adapter into the socket outlet. The battery indica-
tor lamp lights. For first use and after a long period of non-use the charging time is approx.
24 hours, otherwise 10 - 12 hours according to the state of discharge of the battery.
3. Do not place the battery in metal containers, on any kind of metal or on wet surfaces. This
could cause the battery to be short-circuited with subsequent over-heating and possibly
cause an explosion.
Disposal
Please dispose of the blanket in accordance with the directive 2002/96/EG – WEEE (Wa-
ste Electrical and Electronic Equipment). If you have any queries, please refer to the local
autho- rities responsible for waste disposal.
Technical data:
Inhalator
Power input: approx. 10 Watt
Ultrasonic frequency: 2.5 MH
Nebulization rate:
0.2 to 0.7 ml/min according to medicament density
Particle size: 5 μm MMAD
Med. cup capacity: max. 5 ml
Automatic shutdown: after approx. 10 min.
Storage conditions: -10°C to+50°C; 45% to 85% atmospheric humidity
Operating conditions: +15°C to+30°C; 45% to 65% atmospheric humidity
Dimensions: 65 x 50 x 140 mm
Weight: approx. 185g
Accessories:
power line adapter, re-chargeable battery, adult/child mask,
extension tube, protective bag, 5 medicament cup
Re-chargeable battery:
Type: Ni-Mh
Rated voltage: 12V DC
Charging current: 40 to 120 mA
Charging time: initial charge min. 24 hrs. normal 10 to 12 hrs.
normal 10 to 12 hrs.
Rated capacity: 650 mAh
Storage conditions: -18°C to +45°C
Operating conditions: +15°C to +30°C
Weight: 183g
