INSTALLATION (Figure 1 page A)

It is compulsory to ﬁt a sump below the water heater if mounted in a suspended ceiling, under the roof or above living area. A drain connected to the

sewer is required.

LOCATION

INSTALLATION OF A VERTICAL WATER HEATER (Figure 2 page A)

To enable the heating element to be replaced, leave free space below the ends of the tubes of the appliance. The appliances can be mounted on a tripod

(optional)ifthewallisnotstrongenough.Itis,however,obligatoryfortheupperbracketofthewaterheatertobeattachedtothewalltoprevent

it tilting.

INSTALLATION OF A STABLE WATER HEATER (Figure 3 page A)

The water heater must be installed absolutely vertically in such a way as to ensure perfect stability with access to its electrical parts and safety devices.

Allow for access to parts which may need replacing.

INSTALLATION OF A HORIZONTAL WATER HEATER (Figure 4 page A)

Variouswaystoinstall;whenthewaterheaterisinplace,thewaterconnectionsMUSTbeabsolutelyverticalbelowtheappliance.Allowforaccessto

parts which may need replacing.

WATER CONNECTIONS (Figure 5 page B)

All water supply pipes must be thoroughly cleaned before connection. The connection to the hot water outlet must be made using a cast iron or steel

sleeve or a dielectric union in order to avoid corrosion of the tubes (due to direct contact between iron and copper). A brass union must not be used.

UNVENTED INSTALLATION:

Anewsafetydevicewhichconformstocurrentstandards(inEuropeEN1487),pressure0,7and0,9MPa(7and9bar)andsize3/4’’indiametermust

be ﬁtted. The safety valve must be protected from frost.

Hydraulic accessories should not be located between the safety valve and the cold water inlet. A pressure reducer (not supplied) is required when

thewatersupplypressureexceeds0,5MPa(5bar)andwillbettedonthemainsupply.

Connect the safety device to an unpressurised outlet pipe in a frost free environment, with a continuous slope for the evacuation of the water during

heatingupordrainingthewaterheater.Thepipesusedmustsupport1MPa(10bar)and100°C.

IfusingPERpipes,westronglyrecommendthatathermostaticregulatorbettedtothewaterheateroutlet.Itwillbesetaccordingtotheperformances

of the equipment used.

ELECTRICAL CONNECTIONS (Figure 6 page D and E)

Thewaterheatercanbeconnectedandpoweredonlybyasingle-phase230VACorathree-phase400Vmainssupplyaccordingtomodel.Connect

the water heater via a ﬁxed duct with a cross section of 2.5 mm². Use a standard duct (ﬁxed or ring reinforced sheath) to the calibrated receptacle

inthecaver.Inthecaseofappliancesttedwithacableoraplug(notallowedinFrance),connectupdirectly.

Always connect the earth conductor of the cable to the earth ground wire or connect the earth conductor to the appropriate terminal identiﬁed

by the symbol

This connection is a vital safety feature. The green-yellow earth wire must be longer than the phase wires. The installation must be equipped, upstream

oftheappliance,with a bipolar cut-outdevice(contactopening at least 3mm;fuse, breaker switch.) Iftheductsare made of insulatingmaterial,

theelectricalcontactsmustbeprotectedbya30mAearth-leakagebreakerconformingtotheapplicablestandards.Adapttheconnectiontothepower

supply (see diagrams and table).

Before removing the cover, switch off the power.

Thermal circuit breaker:

Allourproductsareequippedwithathermalcircuitbreakerwithmanualresettingwhichshutsoffthepowertothewaterheaterifitbecomesoverhea-

ted.

Ifthecircuitbreakerkeepstripping,

a)switchoffthepowerbeforetakinganyfurtheraction,b)removethecaver,c)checktheelectricalconnections,d)resetthethermalcircuitbreaker.

If the circuit breaker continues to trip, replace the thermostat. Never by-pass the safety device or the thermostat. Connect the power supply only

via the terminal.

Forelectronicproductswithapowerhigherorequalto1800W,itispossibletoswitchinTriPhase400Wusingthefacilitri Kit 400V.

COMMISSIONING / USE

Never switch the water heater on without it being ﬁlled with water.

Before switching on, open the hot water taps, bleed the pipes until no air is present and ﬁll the appliance.

Checkthatthepipesandthedoorsealunderthecaverarenotleaking.Ifthereareanyleakstightengently.Checkthatthewatersafetydevicesare

workingandlltheappliance.Switchontheappliance.After5to20minutesaccordingtothecapacityoftheappliance,watershouldstartdripping

fromthedrainoutlet.Thisisnormalandresultsfromtheexpansionofthewater.Checkthatjointsandsealsarewatertight.Inthecourseofheatingup,

shieldedwaterheatersmaymakeaboilingnoise;thisisnormalanddoesnotindicateanyfaultwiththeappliance.

Toavoidthedevelopmentofbacteria(legionella…)ensurethatatemperatureof60°Cisreachedeveryday.Thethermostatissetatthefactoryat(65°C+-

5°C.or78+-3°Caccordingtomodel).
