• AppleTalk
Active, Not Active
• Default: Active
Ethernet Speed
You can select the network speed to operate the printer.
• Auto Select
• 10Mbps Half D.
• 10Mbps Full D.
• 100Mbps Half D.
• 100Mbps Full D.
• Default: Auto Select
LAN Type
You can select Ethernet or IEEE 802.11b for LAN Type.
This menu appears only when the optional 802.11 interface unit is installed.
• Ethernet
• IEEE 802.11b
• Default: Ethernet
IEEE 802.11b
You can make settings for wireless LAN. This menu appears only when the optional 802.11b interface
unit is installed.
Comm. Mode
You can select the transmission mode for IEEE 802.11b.
• 802.11 Ad hoc
• Infrastructure
• Ad hoc
• Default: 802.11 Ad hoc
• Comm. Mode can also be set using a Web Image Monitor. For details, see Web Image
Monitor Help.
Channel
4. Making Printer Settings Using the Control Panel
154
4
