Ricoh Aficio SP 9100DN [232/344] Printer configuration
![Ricoh Aficio SP 9100DN [232/344] Printer configuration](/views2/1064385/page232/bge8.png)
Messages Description
Transmission Failed The transmission has failed.
Tray Error: Chaptering The paper feed tray specification error has oc-
curred because chaptering as well as the normal
paper use the same tray for printing.
Tray Error: Duplex Printing Selected paper tray cannot be used for duplex
printing.
Waiting for Job Suspension All jobs are being suspended.
Warming Up... The printer is warming up.
• For details about UNIX commands, see UNIX Supplement.
• Check the error contents that may be printed in the configuration page. For details about printing a
configuration page, see p.137 "List/Test Print Menu".
Printer configuration
You can check the printer configuration using telnet.
This section explains the checking procedure for input/output tray and printer language.
• UNIX: Use the "info" command and "rsh", "rcp", "ftp" and "sftp" parameters.
• mshell: Use the "info" command.
Input Tray
Item Description
No. ID number of the paper tray
Name Name of the paper tray
PaperSize Size of paper loaded in the paper tray
status Current status of the paper tray
• Normal:Normal
• NoInputTray: No tray
• PaperEnd:No paper
Output Tray
5. Monitoring and Configuring the Printer
230
5
