• NDS Tree: To enable NDS mode, enter the name of the NDS tree you want to log on to. Use up

to 32 alphanumeric characters.

• NDS Context Name: To enable NDS mode, enter the print server context. Use up to 127 char-

acters.

• Operation Mode: Specify whether to use the interface board as a print server or a remote printer.

• Remote Printer No.: This item is effective when the interface board is specified as a remote printer.

Enter the same number as the number of the printer to be created on the print server (0 to 254

characters).

• Job Timeout: When the interface board is used as a NetWare remote printer, the printer cannot

detect when a print job ends. Therefore, the printer terminates printing when a certain period of

time has elapsed since it last received print data (i.e., when it has not received print data for a

certain period of time). Specify here this period of time (3 to 255 seconds). The initial value is

15 (seconds).

• Frame Type: Select the frame type from the drop-down menu.

• Print Server Protocol: Select the protocol for NetWare from the drop-down menu.

• NCP Delivery Protocol: Select the protocol for NCP delivery.

5. Confirm the settings, and then click [OK].

Configuration is now complete. Wait several minutes before restarting Web Image Monitor.

6. Click [Logout].

• To check that the configuration is made correctly, enter the following from the command prompt.

F:> NLIST USER/A/B

• If the printer works as configured, the name of the print server appears as a connected user.

• If you cannot identify the printer you want to configure, check the printer name with the config-

uration page printed from the printer. For details about printing a configuration page, see p.

137 "List/Test Print Menu".

• If no printer names appear in the list, match the frame types of IPX/SPXs for the computer and

printer. Use the [Network] dialog box of Windows to change the frame type of the computer.

Using Pure IP in the NetWare 5/5.1 or 6/6.5 Environment

Follow the procedure below to connect the printer as a print server in a pure IP environment of NetWare

5/5.1.

• When creating a queued print server in a pure IP environment of NetWare 5/5.1 or NetWare 6.0,

create a print queue on the file server using NetWare Administrator.
