![Ricoh Aficio SP 9100DN [159/344] Pcl menu](/views2/1064385/page159/bg9f.png)
PCL Menu
You can set conditions when using PCL for printing.
Changing the PCL menu
Follow the procedure below to change the setting for Orientation.
1. Press the [Menu] key.
The [Menu] screen appears.
2. Press the [ ] or [ ] key to display [PCL Menu], and then press the [ Enter] key.
3. Press the [ ] or [ ] key to display [Orientation], and then press the [ Enter] key.
4. Press the [ ] or [ ] key to select the orientation, and then press the [ Enter] key.
Wait two seconds. The [Orientation] screen appears.
5. Press the [Online] key.
The initial screen appears.
PCL Menu parameters
Orientation
You can select the page orientation.
• Portrait
• Landscape
• Default: Portrait
Form Lines
You can specify the number of lines per page between 5 and 128.
• Default:
• : 60
• : 64
Font Source
You can set the location of the default font.
• Resident
PCL Menu
157
4
