• RAM
• HDD
• SD
• Default: Resident
• When you select [RAM], you can select only fonts downloaded to the printer RAM.
• When you select [HDD], you can select only fonts downloaded to the optional hard disk.
• When you select [SD], you can select only fonts for downloaded to the SD card.
Font Number
You can specify the ID of the default font you want to use.
• 0 to 63 (Internal)
• 1 to 63 (Download)
Point Size
You can specify the point size you want to use for the default font between 4 and 999.75 in 0.25
increments.
• Default: 12.00 points
• This setting is effective only for a variable-space font.
Font Pitch
You can specify the number of characters per inch you want to use for the default font between 0.44
and 99.99 in 0.01 increments.
• Default: 10.00 pitch
• This setting is effective only for fixed-space fonts.
Symbol Set
You can specify the character set for the default font. Available sets are as follows:
Roman-8, ISO L1, ISO L2, ISO L5, PC-8, PC-8 D/N, PC-850, PC-852, PC8-TK, Win L1, Win L2,
Win L5, Desktop, PS Text, VN Intl, VN US, MS Publ, Math-8, PS Math, VN Math, Pifont, Legal, ISO
4, ISO 6, ISO 11, ISO 15, ISO 17, ISO 21, ISO 60, ISO 69, Win 3.0
• Default: Roman-8
Courier Font
You can select a courier-type font.
• Regular
4. Making Printer Settings Using the Control Panel
158
4
