Ricoh Aficio SP 9100DN [266/344] Windows 95 98 me

When setting the IPv4 address of a printer using DHCP

Use the printer name on the configuration page as the host name.

• For details about printing a configuration page, see p.137 "List/Test Print Menu".

In other cases

Add the IPv4 address and host name of the network printer to the hosts file on the computer used for printing.

Methods of addition vary depending on operating systems.

Windows 95/98/Me

1. Copy \WINDOWS\HOSTS.SAM to the same directory and name it "HOSTS" with no ex-

tension.

2. Open the "\WINDOWS\HOSTS" file created using memo pad files, for instance.

3. Add an IP address and host name to the hosts file using the following format:

192.168.15.16 host # NP

"192.168.15.16" is the IPv4 address, "host" is the printer's host name, and "#NP" is replaced by

comments. Insert a space or tab between "192.168.15.16" and "host", between "host" and "#NP"

respectively, using one line for this format.

4. Save the file.

Windows 2000/XP, Windows Server 2003, Windows NT 4.0

1. Open the hosts file using memo pad files, for instance.

The hosts file is in the following folder:

\WINNT\SYSTEM32\DRIVERS\ETC\HOSTS

"\WINNT" is the directory of the installation destination for Windows 2000/XP, Windows Server

2003, and Windows NT 4.0.

2. Add an IPv4 address and host name to the hosts file using the following format:

192.168.15.16 host # NP

"192.168.15.16" is the IPv4 address, "host" is the printer's host name, and "#NP" is replaced by

comments. Insert a space or tab between "192.168.15.16" and "host", between "host" and "#NP"

respectively, using one line for this format.

3. Save the file.

7. Special Operations under Windows

264
