Messages Description
Printing Printing is in progress.
Processing Data is being processed.
Proxy Address/Port Incorrect Proxy address or Port No. is incorrect.
Proxy User/Password Incorrect Proxy user name or Password is incorrect.
RC Gate Connection Error Failed connection with RC Gate.
Ready The printer is ready to print.
Renewing Remote Certificate Remote Certificate is Renewing.
Replace Black PCU It is time to replace the black photoconductor
unit.
Replace Charger Kit It is time to replace the charger kit.
Replace Cleaning Web It is time to replace the Cleaning Web.
Replace Develop. Unit It is time to replace the development unit.
Replace Develop. Unit (Black) It is time to replace the development unit (black).
Replace Fusing Unit It is time to replace the fusing unit.
Replace PCU It is time to replace the photoconductor unit.
Replace Transfer Belt It is time to replace the transfer belt.
Replace Transfer Cleaning Unit It is time to replace the transfer cleaning unit.
SD Card Authentication failed SD card authentication failed.
Skipped due to Error Skipped the error.
Storage Complete The storage is complete.
Storage Failed The storage has failed.
Supplies Order Call failed The supply order call has failed.
Suspend/Resume Key Error Finisher stop button was pressed.
Transmission Aborted The transmission was interrupted.
Transmission Complete The transmission completion was completed.
Getting Printer Information over the Network
229
5
