Parameter Value configured
Do not make these settings when using other EAP
authentication types.
If you select EAP-TTLS, you can select chap,
mschap, mschapv2, pap, or md5.
If you select PEAP, you can select mschapv2 or
tls.
username "character string" You can specify the login user name for the Ra-
dius server.
Usable characters: ASCII 0x20-0x7e(31 bytes)
other than "@". The default is blank.
username2 "character string" You can specify the phase 2 username for EAP-
TTLS/PEAP phase 2 authentication.
Usable characters: ASCII 0x20-0x7e (31 bytes)
other than "@". The default is blank.
domain "character string" You can specify the login domain name for the
Radius server.
Usable characters: ASCII0x20-0x7e (31 bytes)
other than "@". The default is blank.
password "character string" You can specify the login password for the Ra-
dius server.
Usable characters: ASCII 0x20-0x7e(128
bytes). The default is blank.
srvcert {on | off} You can set the server certificate. The default is
"off".
imca {on | off} You can enable or disable the certificate when
the intermediate certificate authority is present.
The default is "off".
srvid "character string" You can set the server ID and subdomain of the
certificate server.
• You can use this command only when the IEEE 802.11b interface unit is installed.
Remote Maintenance by telnet
221
