Message Problem and solutions
exiting The lpd service has ended and the system is exiting
the process.
Exit pserver (In the print server mode) The print server function
is disabled because the necessary print server set-
tings have not been made.
Frametype =<frame typename> The frame type name is configured to be used on
NetWare.
httpd start. The httpd service has started.
IEEE 802.11b <communication mode> mode Displays IEEE 802.11b communication mode.
inetd start. The inetd service has started.
Interface (interface name): Duplicate IP Address (IP
address).
The same IP (IPv4 or IPv6) address was used. Each
IP address must be unique. Check the address of
the device indicated in [IP address].
< Interface > started with IP: < IP address > IP address (IPv4, or IPv4 address) has been set for
the interface and is operating.
< Interface >: Subnet overlap. The same IP address (IPv4, or IPv6 address) and
the subnet mask is used with other device.
IPP cancel-job: permission denied. The printer could not authenticate the name of the
user attempting to cancel a job.
IPP job canceled. jobid=%d. The spooled job was canceled due to error or user
request.
LeaseTime=<lease time>(sec), RenewTime=<re-
newtime>(sec).
The resource lease time received from the DHCP
server is displayed in [lease time] in seconds. The
renewal time is displayed in [renew time] in sec-
onds.
Login to fileserver <file server name> (<IPX|IPv4|
IPv6>,<NDS|BINDERY>)
(In the print server mode) Login to the file server is
in the NDS or BINDERY mode.
Memory allocate error. Data cannot be obtained.
Disconnect the USB cable, and then connect it.
5. Monitoring and Configuring the Printer
246
