8. Click [SmartDeviceMonitor], and then click [Next >].

9. Click [IPP].

10. In the [Printer URL] box, enter "http://(printer's address)/printer" as the printer's address.

If the server authentification is issued, to enable SSL (a protocol for encrypted communication), enter

"https://(printer's address)/printer" (Internet Explorer 5.01, or a higher version must be installed).

(example IPv4 address: 192.168.15.16)

http://192.168.15.16/printer

https://192.168.15.16/printer

You can enter "http://(printer's address)/ipp" as the printer's address.

If you are using Firefox or Netscape under Windows XP SP 2 or Windows Server 2003, you can

enter IPv6 address as "http://IPv6 printer's address/printer".

11. Enter a name for identifying the printer in [IPP Port Name]. Use a name different from the

one of any existing port.

If a name is not specified here, the address entered in the [Printer URL] box becomes the IPP port

name.

12. [Detailed Settings] to make necessary settings.

For information about the settings, see SmartDeviceMonitor for Client Help.

13. Click [OK].

14. Check that the name of the printer driver you want to install is selected, and then click [Next

>].

15. Change the name of the printer if you want, and then click [Next >].

Select the [Yes] check box to configure the printer as default.

16. Specify whether or not to print a test page, and then click [Next >].

17. Click [Finish].

The printer driver installation starts.

• Auto Run may not work with certain operating system settings. If this happens, launch "Setup.exe" on

the CD-ROM root directory.

• The printer driver with the selected language will be installed. The English printer driver is installed

when the following language is selected: Cestina, Magyar, Polski, Portugues, Suomi.

• A User Code can be set after the printer driver installation. For information about User Code, see the

printer driver Help.

1. Preparing for Printing
