12. Change the printer name if you want, and then click [Next >].
Select the [Yes] check box to configure the printer as default.
13. Click [Next >].
14. Specify whether or not to print a test page, and then click [Next >].
15. Click [Finish].
The printer driver installation starts.
• Auto Run may not work with certain operating system settings. If this happens, launch "Setup.exe" on
the CD-ROM root directory.
• The printer driver with the selected language will be installed. The English printer driver is installed
when the following language is selected: Cestina, Magyar, Polski, Portugues, Suomi.
• A User Code can be set after the printer driver installation. For information about User Code, see the
printer driver Help.
1. Preparing for Printing
40
