5. Once all the values under the Unit Conguration menu
are conrmed, set the Apply Changes parameter to Yes
and press the enter button.
6. The controller will perform an automatic reset
7. If the controller did not reset then verify the APP version
for an error as mentioned under the “Restore parameters
to the controller” section, step 4.
8. This completes the manual programming process.
9. Proceed with setting up individual setting to commission
the unit as required for the application.
Table 3: Unit Conguration
Code Position
Description Values (Default in Bold) Special Condition RTU MPS DPS DPS_H SCU
1 Unit Type
0=Applied Rooftop (RTU)
1=Self-Contained (SCU)
2=Commercial Rooftop (MPS)
3=Rebel Cool Only (DPS/DAH)
4=Rebel Heat Pump (DPS_H)
● ● ● ● ●
2 Control Type
0=Zone Control
1=DAT Control
2=1ZoneVAV
● ● ● ● ●
3 Cooling Type
0 = None
1=Standard Compressorized Clg
2=Chilled Water
3=F&BP
4=Variable Comp Circuit 1
5=Variable Comp Circuit 2
6=VRV
7=NA
8=NA
9=Digital Comp 1 Circuit
10=Digital Comp 2 Circuits
● ● ● ● ●
4
Compressorized
Cooling
Conguration
0=None
1=Generic Condenser
2=2Cmp/2Circ/3Stg
3=3Cmp/2Circ/4StgorVar
(Var used for initial MPS026,
030&035 release)
4=2Cmp/2Circ/2or6StgorVar
(6 stg if 7=2,3,4or5)
5=3Cmp/3Circ/3Stg_NoWRV
6=3Cmp/3Circ/3Stg_WRV
7=4Cmp/2Circ/4StgorVar
8=4Cmp/4Circ/4Stg_NoWRV
9=4Cmp/4Circ/4Stg_WRV
A=6Cmp/2Circ/6StgorVar
B=6Cmp/6Circ/6Stg_NoWRV
C=6Cmp/6Circ/6Stg_WRV
D=3Cmp/2Circ/5StgorVar
E=4Cmp/2Circ/5or8StgorVar
(Var used for initial MPS040)
(8 stg if 7=2,3,4or5)
F=8Cmp/4Circ/8Stg
G=8Cmp/8Circ/8Stg
H=6Cmp/3Circ/6Stg
I=Not Used
J=3 Cmp/3Circ/4Stg
K=Spare
L=1Var/1Circ
M=Var/1STD/1Circ
● ● ● ● ●
5
Generic
Condenser
Stages
1 – 8 Stages (default = 8)/ ●
●
(if 4=4,
5or 6)
●
(if 4=4,
5or 6)
For questions about the procedure please contact the Technical Response team at: TechresponseAAH@daikinapplied.com or 844-521-3928
www.DaikinApplied.com 11 IM 919-4 • MICROTECH III CONTROLLER
