Passwords
Various menu functions are accessible or inaccessible,
depending on the access level of the user, and the password
they enter, if any. There are four access levels, including no
password, Level 2, Level 4, and Level 6, with Level 2 having
the highest level of access. Without entering a password, the
user has access only to basic status menu items. Entering
the Level 6 password (5321) allows access to the Alarm Lists
Menu, Quick Menu, and the View/Set Unit Menus group.
Entering the Level 4 password (2526) allows similar access
as Level 6 with the addition of the Commission Unit Menu,
Manual Control, and Service Menu groups. Entering the Level
2 password (6363) allows similar access as Level 4 with the
addition of the Unit Conguration Menu.
NOTE: Alarms can be acknowledged without entering a
password.
The main password page is displayed when the keypad/display
is rst accessed, the Home Key is pressed, the Back Key is
pressed multiple times, or if the keypad/display has been idle
longer than the Password Timeout (default 10 minutes). The
main password page provides access to enter a password,
access the Quick Menu, view the current Unit State, access the
alarm lists or view information about the unit.
Figure 6: Password Main Page
The password eld initially has a value **** where each *
represents an adjustable eld. These values can be changed
by entering the Edit Mode described below.
Figure 7: Password Entry Page
Entering an invalid password has the same eect as continuing
without entering a password. Once a valid password has been
entered, the controller allows further changes and access
without requiring the user to enter a password until either the
password timer expires or a dierent password is entered.
The default value for this password timer is 10 minutes. It is
changeable from 3 to 30 minutes via the Timer Settings menu.
Navigation Mode
In the Navigation Mode, when a line on a page contains no
editable elds all but the value eld of that line is highlighted
meaning the text is white with a black box around it. When the
line contains an editable value eld the entire line is inverted
when the cursor is pointing to that line.
When the navigation wheel is turned clockwise, the cursor
moves to the next line (down) on the page. When the wheel is
turned counter-clockwise the cursor moves to the previous line
(up) on the page. The faster the wheel is turned the faster the
cursor moves.
When the Back Button is pressed the display reverts back to
the previously displayed page. If the Back button is repeatedly
pressed the display continues to revert one page back along
the current navigation path until the “main menu” is reached.
When the Menu (Home) Button is pressed the display reverts
to the “main page”.
When the Alarm Button is pressed, the Alarm Lists menu is
displayed.
Edit Mode
The Editing Mode is entered by pressing the navigation wheel
while the cursor is pointing to a line containing an editable eld.
Once in the edit mode pressing the wheel again causes the
editable eld to be highlighted. Turning the wheel clockwise
while the editable eld is highlighted causes the value to be
increased. Turning the wheel counter-clockwise while the
editable eld is highlighted causes the value to be decreased.
The faster the wheel is turned the faster the value is increased
or decreased. Pressing the wheel again cause the new value
to be saved and the keypad/display to leave the edit mode and
return to the navigation mode.
Remote Keypad Display Option
The remote user interface is designed for display, system
conguration, set-up and management of Daikin MicroTech III
applied air units.
In addition to the unit-mounted user interface provided with
MicroTech III controls, Daikin HVAC (applied rooftop systems,
indoor vertical self-contained systems, or commercial rooftop
systems) can be equipped with a remote user interface that
handles up to eight units per interface. The remote user
interface provides access to unit diagnostics and control
adjustments. The remote user interface provides the same
functionality as the unit-mounted controller.
About this AHU
The About this AHU menu item provides the user with
the current APP version (application code version), the
conguration code string for this unit, the BSP version
(rmware version) as well as the HMI/OBH GUID version
(software identiers). Each new release of application code
will have a unique set of software identiers. The information
shown in the HMI/OBH GUID version will list the information
needed to verify a match to the APP version.
AHU 01 1/5
Enter Password
Quick Menu
Unit State=________
Alarm Lists
About This AHU
Enter Password� 1/1
Enter Password
****
Keypad/Display
www.DaikinApplied.com 7 IM 919-4 • MICROTECH III CONTROLLER
