Daikin Microtech III [12/100] Controller application software upgrade procedures
![Daikin Microtech III [12/100] Controller application software upgrade procedures](/views2/1656107/page12/bgc.png)
Code Position
Description Values (Default in Bold) Special Condition RTU MPS DPS DPS_H SCU
6 Low Ambient
0 = No
1 = Yes
This position currently has no
eect on unit operation.
7
Condenser
Control
0=Std Method 1
1=Std Method 2
2=Evap ABB
3=Evap MD2
4=Evap MD3
5=Evap DF
6=Not Used
7=EBM
8=INV
9=INV w/MicroC OA Coil
● ● ● ●
8 Damper Type
0=None
1=Single Position 30%
2=Single Position 100%
3=Economizer Airside
4=Economizer Waterside
5=100%OA_D3
6=AirEcon_D3
7=30%_D3
8=EconoAirsideFDD
9=EconFDDD3
Values 1, 2, 5 & 7 only apply if
Position 1 = 0 (RTU), 2 (MPS), 3
or 4 (DPS)
Value 4 only applies if Position 1
= 1 (SCU)
● ● ● ● ●
9 OA Flow Station
0=None
1=DF_015-030 (800)
2=DF_036-042 (802)
3=DF_045-075 (047)
4=DF_080-135 (077)
5=Generic Flow Station
6=Generic Flow Station w/CO2
● ● ● ● ●
10 Heating Type
0=None
1=F&BP Control
2=Staged
3=Modulated Gas, 3-1
4=Modulated Gas 20-1
5=Steam or Hot Water
6=SCR Electric
7=MPSLoGas
8=MPSHiGas
● ● ● ● ●
11
Max Heating
Stages
1-8 Stages (Default = 1) ● ● ● ● ●
12, 13, 14 Max Heat Rise Three Digits (Default = 100) ● ● ● ● ●
15 Supply Fan Type
0=Constant Volume
1=VFD/ABB_BD
2=VFD/DF_BD
3=VFD/MD2_BD
4=VFD/MD3_BD
5=VFD/MD6_BD
6=EBMVAV_DD
7=EBMCAV_DD
8=ABBVAV_DD
9=ABBCAV_DD
● ● ● ● ●
For questions about the procedure please contact the Technical Response team at: TechresponseAAH@daikinapplied.com or 844-521-3928
IM 919-4 • MICROTECH III CONTROLLER 12 www.DaikinApplied.com
