Daikin Microtech III [15/100] Temperature sensors
![Daikin Microtech III [15/100] Temperature sensors](/views2/1656107/page15/bgf.png)
Description of Operation
Temperature Sensors
The MicroTech III controller uses passive negative temperature
coecient (NTC) 10K ohm sensors. These sensors vary their
input resistance to the MCB as the temperature changes. Table
3 details the resistance versus temperature values. For typical
sensor wiring examples refer to Figures 12, 13, and 14.
Table 4: Nominal Input Resistance versus Temperature
Temp (ºF) R nominal (Ω) Temp (ºF) R nominal (Ω) Temp (ºF) R nominal (Ω) Temp (ºF) R nominal (Ω) Temp (ºF) R nominal (Ω)
-40 336.050 -6 103.486 28 36.601 62 14.546 96 6.382
-39 323.889 -5 100.184 29 35.565 63 14.179 97 6.238
-38 312.212 -4 96.999 30 34.562 64 13.822 98 6.097
-37 300.999 -3 93.927 31 33.591 65 13.475 99 5.960
-36 290.229 -2 90.962 32 32.650 66 13.139 100 5.826
-35 279.884 -1 88.101 33 31.739 67 12.811 101 5.696
-34 269.945 0 85.340 34 30.856 68 12.493 10). 5.569
-33 260.396 1 82.676 35 30.000 69 12.184 103 5.446
-32 251.218 2 80.103 36 29.171 70 11.884 104 5.325
-31 242.397 3 77.620 37 28.368 71 11.591 105 5.208
-30 233.918 4 75.222 38 27.590 72 11.307 106 5.093
-29 225.766 5 72.906 39 26.835 73 11.031 107 4.981
-28 217.928 6 70.670 40 26.104 74 10.762 108 4.872
-27 210.390 7 68.510 41 25.394 75 10.501 109 4.766
-26 203.139 8 66.424 42 24.707 76 10.247 110 4.663
-25 196.165 9 64.408 43 24.040 77 10.000 111 4.562
-24 189.455 10 62.460 44 23.394 78 9.760 112 4.463
-23 182.998 11 60.578 45 22.767 79 9.526 113 4.367
-22 176.785 12 58.759 46 22.159 80 9.298 114 4.273
-21 170.804 13 57.001 47 21.569 81 9.077 115 4.182
-20 165.048 14 55.301 48 20.997 82 8.862 116 4.093
-19 159.506 15 53.658 49 20.442 83 8.652 117 4.006
-18 154.169 16 52.069 50 19.903 84 8.448 118 3.921
-17 149.030 17 50.533 51 19.380 85 8.249 119 3.838
-16 144.081 18 49.047 52 18.873 86 8.056 120 3.757
-15 139.313 19 47.610 53 18.380 87 7.868 121 3.678
-14 134.720 20 46.220 54 17.902 88 7.685 122 3.601
-13 130.295 21 44.875 55 17.438 89 7.506 123 3.526
-12 126.031 22 43.574 56 16.988 90 7.333 124 3.453
-11 121.921 23 42.315 57 16.551 91 7.164 125 3.381
-10 117.960 24 41.097 58 16.126 92 6.999 126 3.311
-9 114.141 25 39.917 59 15.714 93 6.839 127 3.243
-8 110.460 26 38.776 60 15.313 94 6.682 128 3.176
-7 106.910 27 37.671 61 14.924 95 6.530 129 3.111
Description of Operation
www.DaikinApplied.com 15 IM 919-4 • MICROTECH III CONTROLLER
