HANDHELDWIRELESSMICROPHONEHANDHELDWIRELESSMICROPHONE
18 19
1.PARTSNAMESANDFUNCTIONS
(Fig.1)
(Fig.2)
1.Grille:Protectscartridge,prevents"POP"noiseandpreventsmicrophone
fromrollingwithpolygonalshape.
2.ColorRing:Forfrequencydifferentiation.
3.Housing:Upperportiontobeconnectedtoacapsulemoduleandbattery.
Internally,itholdstransmitterPCB.
4.FunctionsofLCDDisplay
5.BatteryCompartment:Designedtoaccommodatetwo1.5V(AA)batteries.
6.BatteryCap:Coversbatteryinthebatterycompartment.
7.Anti-rollRing:Forfrequencydifferentiation.
8.ACTSignalReceptor:ReceivingACTsignalandadjustingfrequency
automatically.
2.BATTERYINSERTION
3. FUNCTIONSOFLCDDISPLAY
1.Unscrewbatterycap(6)inacounter-clockwisedirection.
2.Inserttwo1.5V(AA)batteriescorrectlyintothebatterycompartmentwith
thepositivepole(+)pointsatthemicrophonecapsule.Then,screwthe
batterycap(6)backtomicrophoneasshowninFig.2.
ERR
GROUP
CHANNEL
BAT
ERRno01EEPROMisnotbeingprogrammedorinternaldataerror.
ERRno02Fortestingonly.
ERRno03Thefrequencyyouareabouttoprogramintothesystemexceeds
microphone'supperlimit.(Atthistime,microphoneisstill
operatableandthefrequencyremainsunchanged.Toclearthe
"ERR"messageinLCDdisplay,simplyturnoffthepowerand
switchbackon.)
ERRno04Thefrequencyyouareabouttoprogramintothesystemisbelow
microphone'sfrequencylowerlimit.(Atthistime,microphoneisstill
operatableandthefrequencyremainsunchanged.Toclearthe
"ERR"messageinLCDdisplay,simplyturnoffthepowerand
switchbackon.)
→
→
→
→
2."Group"&"Channel":Whenbothitemsareshown,theyindicatethattheuser
iscurrentlyusingthepre-programmedfrequencyinthereceiver.
3."Channel"Only:If"Channel"istheonlyitemshowninthedisplay,itindicates
theuserisusingthepersonalizedfrequency.
4.BatteryStatus:
BatteryStatus:Whenthebatteryhaslessthan10%powerremaining,batteries
mustbereplaced.Ifundervoltagecontinues,LCDwillshow"PoFF"andshutdown
thesystemtoavoidbatterybeingover-discharged.
100% 80% 40% 10% 0%
5.SwitchOff:
Whenswitchthepowerknobto"Off"position,LCDwillshow"PoFF"first.
Then,thesystemiscompletelyshutdownandnofurthermessagewillbe
displayed.
1.ERRMessage:When"ERR"appears,itmeans"OperationError".Pleaserefer
tothefollowingcodestodiagnosewhicherroryouareexperiencing.
PS:Whenthemicrophoneisnotinuse:
Makesurethepowerofthemicrophoneisoff.Ifthemicrophonewillnot
beusedforsometime,pleaseremovethebatteriesfromthebattery
compartmenttoavoidbatteryleakageandresultindamagedbattery
springsandcircuit.Ifarechargeablebatterywasused,takeitoutand
rechargeit.
1 3 4
5
2
768
GROUP
CHANNEL
BAT
