ACTSINGLECHANNELWIRELESSRECEIVER ACTSINGLECHANNELWIRELESSRECEIVER
ACT
ACT
ACT EXIT
OperationofACTFeature:
A.OperatingProcedures.
B.HowtoOperate?
a.AtLCDpaneldisplays"Group"and"Channel"modekeystroke"ACT"
button.ACTmodeisactivatedwhen"ACT"wordappearsonthe
LCDpanel.
b.Movemicrophonetowardtoreceiverwithinthedistancearound30cm,
andfacethe"ACT"markedsideonthemicrophonetothe"ACT"
buttononthepanelofreceiver,seebelowfigure.
c.ACTfunctionwillreleaseautomaticallyoncethetransmitterchannelis
lockedon.Simultaneously,"Group"and"Channel"modewillbe
backshowingontheLCDpanel.Bothtransmitterandreceiver
shouldshowthesame"Group"and"Channel".Thisindicates
transmitterfrequencyset-upissuccessful.Ifunsuccessful,repeatstep
"A".
7. COMPUTERNETWORKINTERFACEOPERATION
1.Exceptforreceivermodule,bothreceiverwithLCDdisplayhavethemost
advancefunctionofcomputer-network-interfacedcontrollingsystem.
2.WiringInstruction
② Pleaseconnectoneendofthephonecable(included)toremoteconnector's
"OUT"jack(9)onthebackofthefirstreceiverandconnecttheotherendof
cabletoremoteconnector's"IN"jack(9)onthebackofsecondreceiver.
(Showsinfigure9).Continuesuchparallelconnectionwithremaining
receivers.Onceallreceiversareparallelsconnected,connectaphonecable
fromremoteconnector's"IN"jack(9)onthebackoffirstreceivertoMIPRO-
DVconverter.
① Connectthenetworkinterfaceremoteconnector(9)onthebackofthe
receivertotheinterfaceconverter(requiresatleast2linkingcablesforeach
pairing).Then,useRS-232cableconnectstheconvertertotheRS-232COM
PORTonthecomputer.
(Fig.9)
14 15
CONVERTER
TOPCRS-232COMPORT
TOPCKEYBOARDCONNECTOR
TOKEYBOARD CONNECTOR
RX1
RX2
RX3
PC
ACT
MENU
GROUP
SCAN
