Mipro ACT707S [5/14] Act single channel wireless receiver

6 7

ACTSINGLECHANNELWIRELESSRECEIVER

5.19/2-INCHUNITSRECEIVERINSTALLATION

1.Singlehalf-rackreceiver

① Rackmountreceiverwithoptionalrackmountkitandfastenwithscrewson

bothsides.(Fig.5)

(Fig.5)

①

②

③

Unfastenthetopandbottomscrewsforeachreceiver.Pushthereceiversnext

toeachother.

Insertthefixedsteelplatebetweenthereceiver(topandbottom),alignand

fastenthescrewstightlyasshowninFig.6.

Afterbothreceiversarefixedfastentherackmountkitonbothsideofthe

receiverasshownonFig.6.

2.Dualhalf-rackreceivers

(Fig.6)

ACTSINGLECHANNELWIRELESSRECEIVER

3.Onthefrontpanelofthereceiver,4openingsarepre-drilledforinstant

installationonthestandard19-inchrackcase.(ShowsinFig.7)

4.Toensurebestreceptionpossible,receivermustbeinstalledatleastone

meteraboveground.Inaddition,thedistancebetweentransmitterand

receivermustbemorethanonemeterandawayfromnoise.(Showsin

Fig.8)

(Fig.7) (Fig.8)
