ACTSINGLECHANNELWIRELESSRECEIVER ACTSINGLECHANNELWIRELESSRECEIVER
2.PARTSNAMEANDFUNCTIONS
FrontPanel：
RearPanel：
(Fig.1)
(Fig.2)
(1)FrontAntennaAInputConnector:Allowsanoptionalrear-to-front
Antennakitforfrontantennaplacement.
(2)PowerSwitch&Indicator:Whenswitchisturnedon,redindicator
illuminatestodenotenormalpowerstatus.
(3)ReceiverPanel:ColorLCDPanel.
(4)FrontAntennaBInputConnector:Allowsanoptionalrear-to-front
Antennakitforfrontantennaplacement.
(5)AntennaBinputConnector:AntennaBconnectorcanbeinstalledwith
antennadirectlyandprovidespowerforantennabooster.
(6)BalancedAudioOutputJack:WithCannon/XLRtypeconnectorprovides
balancedaudiooutputsignalfromthisjacktotheamplifier.
(7)UnbalancedLevelSwitch:"MIC"selectionisfor"Microphone-level"output.
"LINE"selectionisfor"Line-out"leveloutput.
(8)UnbalancedAudioOutputJack:With1/4PhoneJackprovidesaudio
outputsignalfromthisjacktotheamplifier.
(9)ComputerNetworkInterfaceConnector:Networksockettoconnecttothe
computerizedsystem-monitoringprogram.
(10)DCInputSocket:Theinputsocketfor12VoltDCpower.Pleasenote
thatthepolarityofthecentralpininthesocketispositive(+).
(11)AntennaAInputConnector:AntennaAconnectorcanbeinstalledwith
antennadirectlyandprovidespowerforantennabooster.
(12)RackmountBracket:ToinstallthereceiverintoanEIA19-inchstandard
rackcase.
λ
5 6 7 8
10
11
9
12
RF AF
MHz
G/CH
VOL
FREQ SQ
REMONAME
BATANT
BA
ACT
MENU
GROUP
SCAN
