12 13
ACTSINGLECHANNELWIRELESSRECEIVER ACTSINGLECHANNELWIRELESSRECEIVER
(5)NAME:Indicatesorsetupsthenameofcurrentchanneluser. (6)REMO:Indicatesorsetupthereceiveraddressandstatusofremotecontrolling.
A.OperatingProcedures.
A.OperatingProcedures.
B.HowtoOperate?
B.HowtoOperate?
a.Maximum6charactersareallowed(SelectfromcapitalizedEnglishletter,numbers,
+-x/,andspace).
b.Push"UP"or"DOWN"buttonintosetupmodeandthecharacteronthefarleftwill
startblinking.(Therewillbenoblinkingifthereisnocharacterinthespecificspace).
c.Push"UP"or"DOWN"buttontoselectdesiredcharacterandconfirmbypushing
the"MENU"button.Onceconfirmed,thenextcharacterwillstartblinkingandready
forsetup.
d.RepeatstepcuntilALL6charactersareset.
a.ACT-BUSinterfaceisadaptedforMIPROWirelessReceiverModule.WithMIPRO
InterfaceConverterandMonitoringSoftware,upto64receivermodulescanbe
remote-controlledsimultaneouslyviaaPC.
b.Addresscanbesetwithintherangeof01-64.Underremotecontrolmode,each
receivermoduleMUSThasitsownaddress.If2differentreceivermodulesare
usingthesameaddress,itwillcauseconflictionandresultinmonitoringerror.
However,ifnotunderremotecontrolmode,operationwillremainnormalevenif2
differentreceivermodulesareusingthesameaddress.
c.Inremotecontrolmode,"ON"willbeshownintheLCDdisplaypanelandthe
numbernexttothemessageistheaddressofthereceivermodule.However,
"OFF"willbeshownisthesystemisnotremotelylinkedtothePC.
d.Push"UP"or"DOWN"buttontochangereceiveraddressandverifybypushingthe
"MENU"button.
Save
NAME
MENU
A
MENU
NEXT
EXITA MENU
DOWN UP
DOWN UP
save
REMO
MENU
64
EXITMENU
DOWN UP
ACT
MENU
GROUP
SCAN
ACT
MENU
GROUP
SCAN
