BELTPACKTRANSMITTER BELTPACKTRANSMITTER
20 21
1.PARTSNAMESANDFUNCTIONS
(Fig.1)
1.AFInputJack:Connectstoalavaliereorheadsetmicrophone.(See5ways
ofconnectiononAFInputConnections)
2.PowerSwitch:Tumspower"on"and"off"ofthetransmitter.
3.BatteryStatusIndicator:Indicatesthepoweron/offandbatterystatus.
(a)Whenpowerswitchisturnedon:TheLEDindicatorflashesbriefly,
indicatingnormalbatterystatus.
(b)WhenREDlightilluminatesateitherpoweronorduringusage:The
batterylevelislow,therefore,anewbatteryreplacementisthusnecessary.
4.TransmittingAntenna:1/4transmittingantenna.
5.TransmitterHousing:PackagesthePCBandbattery.
6.FunctionsofLCDDisplay
7.ACTSignalReceptor:ReceivingACTsignalandadjustingfrequency
automatically.
8.GainControl:Adjuststhedesirousinputgain.
9.GT/MTLevelSelector:SwitchGTpositionforelectricguitarusageand"Line
In".GainControlisirrelevantfor"GT".Switchto"MT"forcondenser
microphoneorwiredmicrophone.GainControlworksin"MT"forinput
sensitivityadjusting.
10.BatteryCompartmentandCover:Accommodatestwo1.5V(AA)batteries.
11.DetachableBeltClip:Allows360degreesrotatingtosuittransmittingangles.
Todetachsimplyuseascrewdriverata45degreeangletounfasten.see
diagram.
λ
1
2
11
3
5
8
9
7
4
6
ACTSERIES
GROUP
CHANNEL
BAT
GAIN MTGT
10
OFF ON BATT.
LOW
