Mipro ACT707S [7/14] Freq menu
![Mipro ACT707S [7/14] Freq menu](/views2/1665429/page7/bg7.png)
10 11
ACTSINGLECHANNELWIRELESSRECEIVER ACTSINGLECHANNELWIRELESSRECEIVER
FREQ
MENU
(2)FREQ:Indicatesthefrequencythatiscurrentlyinuse.
A.OperatingProcedures.
B.HowtoOperate?
a.Afterpush"MENU"buttonandselectthe"FREQ"frame,itwillshowthefrequency
thatissetundertheGROUPandCHANNELthatonehadselectedpreviously.
B.Theoperationonlyfordisplayingfrequency,notforthefunctionofchanging
frequency.
(3)SQ:IndicatesorsetupstheSquelchlevel.
a.Usercansetthesquelchlevelwithintherangeof01-99.
b.Tosetthesquelchlevel,simplybypushingthe"UP"or"DOWN"buttonandconfirm
themodificationbypushing"MENU"button.
c.Thebiggerthesettingnumber,thelowerthesensitivity.
(4)VOL:IndicatesVolumeLevelisatOnorMuteposition.
A.OperatingProcedures.
B.HowtoOperate?
Theoperationprovidsmutecontrolswitch
Push"UP"or"DOWN"Buttonallowsonetoswitchvolumeto"ON"or"Mute"status.
A.OperatingProcedures.
B.HowtoOperate?
AFbarandAnt.A,BofLCDpanelwillnotdisplayedwhenthereceivermoduleis
atMutestatus.ToascertainifreceiverisatMutestatus,pressMenukey,select
Volume.IfLCDindicates"Mute"itisaMutestatus.IfLCDindicates"On"audiois
operatingnormally.
C.CAUTIONS:
SQMENU 01 EXITMENU
DOWN UP
Save
VOL
MENU
MUTE
EXIT
DOWN UP
ACT
MENU
GROUP
SCAN
ACT
MENU
GROUP
SCAN
ACT
MENU
GROUP
SCAN
