Defort DSP-400CN [6/64] If in doubt consult a qualified electrician

!IF IN DOUBT CONSULT

A QUALIFIED ELECTRICIAN!

All electrical connections e.g. extension cable, must

be of an approved waterproof type for outdoor use.

Exten sion cables must be three-core, one of which is

EARTH.

Always fully unwind extension cables before use.

Connection to the mains power supply must be via an

approved residual current device (RCD), with a residu-

al operating current not exceeding 30mA.

MAINTENANCE

There are no user serviceable parts in this appli-

ance. If the appliance appears to be blocked, switch

off the power at the mains, remove the plug from the

socket and check the appliance for blockages (see

‘Blockages’).

BLOCKAGES

If you suspect the pump has become blocked, switch

off the power at the mains socket remove the plug and

exa mine the turbine. The turbine can be accessed by

remo ving the securing screws in the base and/or sub

base. Alternately try reaching the suspected blockage

through the outlet pipe in the side of the pump.

Always ﬂ ush through with clean water after every use.

IMPORTANT: During maintenance or cleaning never

rest the appliance of the on the turbine (impeller).

GENERAL USE

• This pump is NOT designed for continuous opera-

tion e.g. as a swimming pool or pond circulation

pump.

• If used as an intermittent pump to circulate water

in an ornamental pond it must be sited in a sump

or behind a suitable barrier to stop pond life being

suc ked into it.

• Use a rope to lower the pump into deep water -nev-

er lower the pump by its power cord or delivery pipe

at anytime.

• Ensure there are no obstructions around the inlet

openings around the base of the pump. The inlet

ope nings must be clear of mud or sludge at the bot-

tom of a pool.

• It would be advisable to stand the pump of a solid

plat form at the bottom of the pool to keep it upright,

if practical to do so.

• If the pump is used to drain a swimming pool it must

only be used when the pool is completely empty of

people.

• It is important that the ﬂ oating switch is allowed to

reach its ON height in the water. It must also be

able to ﬂ oat down without obstruction in order for it

to switch off when required.

• After use allow the pump to run using clean water

for 2-3 minutes in order to remove residues and

parti cles that may have accumulated in the pump

and out let hose.

NOTE:

If the level of water becomes to low, any sludge in the

shaft will dry out more quickly and this may prevent

the pump from restarting. To ensure the pump works

efﬁ ciently the bottom of the shaft must be kept free of

sludge as far as possible and cleaned on a regular ba-

sis when not in use.

OPERATING INSTRUCTIONS

Automatic Operation

When the pump is lowered into the water and the pow-

er is switched on, it will start to operate as soon as the

ﬂ o ating switch reaches the minimum activation height

in the water.

Remember: The pump must be carried by, and placed

in the water using the carry handle or if the water is

deep, be lowered on a rope tied to the carry handle.

Manual Operation

Where manual operation is preferred, the motor can be

activated by raising the ﬂ oating switch by hand (ON) or

lowering it by hand (OFF).

Ensure the distance between the ﬂ oat switch and the

latch holder is not too small as to restrict the up and

down movement of the ﬂ oat switch.

Defort DSP-400CN [6/64] If in doubt consult a qualified electrician
