![Daikin EUWA15HDW15 [10/18] History menu t t t t t](/views2/1680861/page10/bga.png)
9
a SENSOR ACCURACY
INLET WATER SENSOR
OFFSET : 0.0°C
To calibrate the sensor for inlet water
temperature measurement.
Timers menu –
rr
rr
r
z GENERAL TIMERS
LOADUP : 000s - DWN : 000s
FLOWSTART : 00s
COMPR. STARTED : 00s
To check the actual value of the general
software timers.
a
COMPRESSOR TIMERS
GRD 1 : 000s AREC 1 : 000s
GRD2 : 000s AREC2 : 000s
GRD3 : 000s AREC3 : 000s
To check the actual value of the
compressor timers.
Safeties menu –
gg
gg
g
The "safeties" menu provides useful information for trouble shooting
purposes.
z UNIT SAFETY
REVERSE PHASE PROT.
INLET WATER : + 18.0°C
AMB. : +22.0°C / COOLING
To consult information about the unit
safety which caused the shutdown and
to check the unit status at shutdown.
e
C1 SAFETY
OUTL. WATER1 : +13.0°C
INLET WATER : +18.0°C
AMB. : +22.0°C / COOLING
e
C2 SAFETY
OUTL. WATER2 : +13.0°C
INLET WATER : +18.0°C
AMB. : +22.0°C / COOLING
a
C3 SAFETY
OUTL. WATER3 : +13.0°C
INLET WATER : +18.0°C
AMB. : +22.0°C / COOLING
TEMPERATURE LIMITS
OUTL. WATER : +04_+20°C
INLET WATER : +07_+27°C
AMB. TEMP. : -5_+43°C
To check the status of circuit 1 at
activation of one of the circuits safeties.
To check the status of circuit 2 at
activation of one of the circuits safeties.
To check the status of circuit 3 at
activation of one of the circuits safeties.
To consult the outlet water, inlet water
and ambient temperature limits.
History menu –
tt
tt
t
The "history" menu contains all the information concerning the latest
shutdowns.
z UNIT HISTORY : 002
REVERSE PHASE PROT.
INLET WATER : +18.0°C
AMB. : +22.0°C / COOLING
To consult information about the
number of shutdowns, the unit safety
which caused the most recent shutdown
and the unit status at this shutdown.
e
C1 HISTORY : 001
OUTL. WATER1 : +13.0°C
INLET WATER : +18.0°C
AMB. : +22.0°C / COOLING
e
C2 HISTORY : 003
OUTL. WATER2 : +13.0°C
INLET WATER : +18.0°C
AMB. : +22.0°C / COOLING
a
C3 HISTORY : 001
OUTL. WATER3 : +13.0°C
INLET WATER : +18.0°C
AMB. : +22.0°C / COOLING
To consult information about the
number of circuit 1 shutdowns and the
circuit status at the most recent
shutdown.
To consult information about the
number of circuit 2 shutdowns and the
circuit status at the most recent
shutdown.
To consult information about the
number of circuit 3 shutdowns and the
circuit status at the most recent
shutdown.
Info menu –
yy
yy
y
z UNIT INFORMATION
UNITNAME : EUWA 30
REFRIGERANT : R22
MANUFACT. NR. : 0000000
To consult additional information about
the unit such as the unit name, the
refrigerant used and the manufacturing
number.
a
UNIT INFORMATION
SOFTWARE : V01.000
To consult information about the
controller's software version.
Input/output menu –
uu
uu
u
The "input/output" menu gives the status of all the digital inputs and
the relay outputs of the unit.
z DIGITAL INPUTS
SAFETY 1 : OK
SAFETY 2 : OK
SAFETY 3 : OK
To check the status of the circuit
safeties.
e
DIGITAL INPUTS
FLOWSWITCH : FLOW OK
e
DIGITAL INPUTS
DUAL SETPOINT : SETP. 1
REM. START / STOP : START
REV. PHASE PR. : OK
e
RELAY OUTPUTS
COMPR. 1 : NOT ACTIVE
COMPR. 2 : NOT ACTIVE
COMPR. 3 : NOT ACTIVE
To check the status of the flowswitch.
To check the status of the remote
setpoint selection switch, the remote on/
off switch and the reverse phase
protector.
To check whether or not the different
compressors are activated.
e
RELAY OUTPUTS
LPBYPASS 1 : NOT ACTIVE
LPBYPASS 2 : NOT ACTIVE
LPBYPASS 3 : NOT ACTIVE
To check the status of the low pressure
bypass switches.
e
RELAY OUTPUTS
FANSP. RY 1 : ACTIVE
FANSP. RY 2 : ACTIVE
FANSP. RY 3 : ACTIVE
e
RELAY OUTPUTS
ALARM : NOT ACTIVE
OPERATION : ACTIVE
PUMP : ACTIVE
a
RELAY OUTPUTS
EV. HEATER : NOT ACTIVE
To check the status of the fanspeed
relays.
To check the status of the alarm, the
operation and the pump voltage free
contacts.
To check the status of the evaporator
heater. However, the evaporator heater
option is not offered by Daikin.
CHANGE PASSWORD
NEW PASSWORD : 0000
CONFIRM : 0000
To change the user password.
User password menu –
qq
qq
q
e
SETPOINT - PASSWORD
PASSWORD NEEDED TO
CHANGE SETPOINTS : Y
To define whether or not a password is
needed to change the temperature
setpoint.
