13/62
coating that enhance the resistance to the corrosion. The treatment is recommended in all application where
moderate risk of corrosion exist (eg: urban, costal, industrial environments) - Opt. incompatibility 139.
Electrical options – On request
Compressor thermal overload relays (opt. code 11 – Multi V units only)
Available on Multi V units only. - Opt. incompatibility 95.
Under over voltage control (opt. code 15)
Electronic device that monitors and displays input voltage. It stops the chiller in case of phase loss, wrong phase
sequence, or voltage exceeding minimum and maximum allowed values.
Energy meter (opt. code 16 – Multi V units only)
Device installed inside the control box that displays chillers’ electrical power parameters such as input line
voltage and phase current, input active and reactive power, active and reactive energy. An integrated RS485
module allows a Modbus communication to an external BMS.
Speedtrol (opt. code 42 – Multi V units only) - Opt. incompatibility 99-142a-161.
Continuous fan speed regulation on the first fan (VFD driven) of each circuit. It allows unit operation down to -
18ºC (available for standard and low sound version).
Evaporator flow switch (opt. code 58)
Supplied separately to be wired and installed on the evaporator water piping (by the customer). The installation
of the flow switch in mandatory.
Compressors circuit breakers (opt. code 95)
Safety devices that include in a single device all safety functions otherwise provided by standard fuses and
optional thermal relays, such as protection against overcurrent, overload, current unbalance - Opt.
incompatibility 11.
Fans speed regulation +fans silent mode (opt. code 99)
Fans speed regulation: continuous modulation of the fans’ speed for optimal condensation control at low ambient
temperatures.
Fans silent mode: This feature allows the user to set up customized time bands to reduced fans’ speed rotation
and therefore sound emission in those areas where quiet is a mandatory requirement during specific time of the
day (e.g. night operation).
Note: option 99 is standard on Single V units (phase cut).
Note: option 99 is standard on Multi V units reduced sound (inverter).
Ground fault relay (opt. code 102 – Multi V units only)
To shut down the unit in case of a ground fault condition is detected.
Inverter kit for pumps:
-
INVERTER KIT FOR 1 CENTR PUMP LOW LIFT (opt. code 120e)
-
INVERTER KIT FOR 1 CENTR PUMP HIGH LIFT (opt. code 120f)
-
INVERTER KIT FOR 2 CENTR PUMP LOW LIFT (opt. code 120g)
-
INVERTER KIT FOR 2 CENTR PUMP HIGH LIFT (opt. code 120h)
the Inverter kit must be associated with the corresponding hydronic kit (opt.code 78/79/80/81). It is standardly
not compatibile with kit pump + water tank. Contact factory to evaluate feasibility.
The inverter kit can be used for the following purposes:
- Adjusting the water flow rate during unit commissioning.
- Control the pump speed via external input from Building Management System (BMS)
For this application a 0-10V signal for the pump speed must be provided from the plant manager according to
the specific control strategy of the plant. The water must be within the minimum and maximum value allowed
for the unit (refer to the “Operating limit” chapter). The change in water flow rate must not be exceed more
than 10% of the design water flow rate per minute.
- Set a “thermostat off” pump speed. Providing the unit with the inverter kit for the on-board pump is
possible to manage two different water flow settings. A setting for water flow during the "Thermostat ON" mode
(when the chiller is actually providing cooling to the plant), and a set for the “thermostat off” mode (when the
plant load is satisfied and the compressors are waiting to start). This feature allows to achieve energy saving
on plant operating cost by reducing the speed of the pumps when the chiller has reached the set point.
