English
4
LAN
1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon
RTL8125AG):
•
Supports Dragon 2.5G LAN Soware
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and
Streaming Modes
- User Customized Priority Control
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
1 x Intel Gigabit LAN 10/100/1000 Mb/s (1 x Intel® I219V):
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Wireless
LAN
•
Intel® 802.11ax WiFi Module
•
Supports IEEE 802.11a/b/g/n/ax
•
Supports Dual-Band (2.4/5 GHz)
•
Supports high speed wireless connections up to 2.4Gbps
•
2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
•
Supports Bluetooth 5.0 + High speed class II
•
Supports MU-MIMO
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x Optical SPDIF Out Port
•
2 x USB 2.0 Ports (Supports ESD Protection)
•
1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
(ASMedia ASM3242) (Supports ESD Protection)
* Ultra USB Power is supported on USB3_3_4 ports.
* ACPI wake-up function is not supported on USB3_3_4 ports.
•
4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
•
2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
