English
24
PCIE Slot Speed (For CPU with 48 PCIe lanes)
PCIE Slot Speed (For CPU with 44 PCIe lanes)
PCIE Slot Speed (For CPU with 28 PCIe lanes)
PCIE1
x16
PCIE2 x8
PCIE3 x16
PCIE4 x1 (PCH)
PCIE5 x8
*If M.2 PCI Express modules are installed on M2_1 and M2_2, PCIE2 will be disabled.
PCIE1 x16
PCIE2
x4
PCIE3 x16
PCIE4 x1 (PCH)
PCIE5 x8
*If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled.
PCIE1 x16
PCIE2 x4
PCIE3 x8
PCIE4 x1 (PCH)
PCIE5 N/A
*If a M.2 PCI Express module is installed on M2_1, PCIE2 will be disabled.
