1.6 USB 3.2 Gen2 x2 Module
Specications
Platform •
Size: 1.45-in x 1.65-in, 3.7 cm x 4.2 cm
Controller •
ASMedia ASM3242 Controller
M.2
•
Proprietary design for Asrock specic motherboard
* Please note that plugging into other M.2 connector may
damage the motherboard and this module
Connector
•
1 x USB 3.2 Gen2x2 Type-C Port (Supports ESD Protection
(ASRock Full Spike Protection))
*For charging Type-A USB devices, we suggest using the Type-A
connectors on your motherboard.
*is port supports power outputs up to 5V/3A. For charging Type-C
USB devices, the device should support Type-C standards
to adjust the current because it will be dierent in Power On state (3
Amp) and Sleep state (1 Amp).
*Some Type-C USB devices may only be charged by its own adapter.
OS
•
Microso® Windows® 10 64-bit
USB 3.2 Gen2x2
Type-C Port
TBT_M2_1
