ASRock X79 Extreme4-M Motherboard
Türkçe
HDMI_SPDIF Fişi HDMI_SPDIF şi, SPDIF ses
(2-pinli HDMI_SPDIF1)
çıkışını HDMI VGA kartına
(bkz. s.2 No. 34)
sağlar, sistemin HDMI Dijital
TV/projektör/LCD cihazlarını
bağlamasına izin verir. Lütfen
HDMI VGA kartının
HDMI_SPDIF konektörünü bu
şe bağlayın.
1.5 Akıllı Anahtarlar
Bu anakartta üç akıllı anahtar bulunur: güç anahtarı, sıfırlama anahtarı ve CMOS'u
temizleme anahtarı; bunlar kullanıcıların hızlı bir şekilde sistemi açıp kapatmalarını
veya CMOS değerlerini temizlemelerini sağlar.
Güç Anahtarı Güç Anahtarı, kullanıcıların
(PWRBTN)
hızlı bir şekilde sistemi açıp
(bkz. s.2 No.28)
kapatmalarını sağlayan akıllı
bir anahtardır.
Sıfırlama Anahtarı Sıfırlama Anahtarı,
(RSTBTN)
kullanıcıların hızlı bir şekilde
(bkz. s.2 No.27)
sistemi sıfırlamalarını
sağlayan akıllı bir anahtardır.
CMOS'u Temizleme Anahtarı CMOS'u Temizleme Anahtarı,
(CLRSBTN)
kullanıcıların hızlı bir şekilde
(bkz. s.3 No.17)
CMOS değerlerini
temizlemelerini sağlayan akıllı
bir anahtardır.
