ASRock J3455 Pro BTC+ [11/52] English
![ASRock J3455 Pro BTC+ [11/52] English](/views2/1688617/page11/bgb.png)
6
English
No. Description
1 USB 2.0 Header (USB_5_6)
2 Clear CMOS Jumper (CLRMOS1)
3 System Panel Header (PANEL1)
4 Power Button (PWRBTN1)
5 Reset Button (RSTBTN1)
6 ATX Power Connector (ATXPWR2)
7 CPU Fan Connector (CPU_FAN1)
8 ATX Power Connector (ATXPWR1)
9 Chassis Intrusion Header (CI1)
10 COM Port Header (COM1)
11 SATA3 Connector (SATA_1)
12 Mining Port (M_Port1)
13 Mining Port (M_Port2)
14 Mining Port (M_Port3)
15 PCIe Power Connector (PWR_PCIE3)
16 System Fan Connector (SYS_FAN3)
17 PCIe Power Connector (PWR_PCIE4)
18 PCIe Power Connector (PWR_PCIE5)
19 System Fan Connector (SYS_FAN5)
20 PCIe Power Connector (PWR_PCIE6)
21 PCIe Power Connector (PWR_PCIE7)
22 System Fan Connector (SYS_FAN7)
23 PCIe Power Connector (PWR_PCIE8)
24 System Fan Connector (SYS_FAN8)
25 System Fan Connector (SYS_FAN6)
26 System Fan Connector (SYS_FAN4)
27 System Fan Connector (CHA_FAN1)
28 System Fan Connector (CHA_FAN2)
29 System Fan Connector (CHA_FAN3)
30 ATX 12V Power Connector (ATX12V1)
