ASRock J3455 Pro BTC+ [22/52] Smart switches
![ASRock J3455 Pro BTC+ [22/52] Smart switches](/views2/1688617/page22/bg16.png)
17
English
J3455 Pro BTC+
2.5 Smart Switches
e motherboard has two smart switches: Power Button and Reset Button.
Power Button
(PWRBTN1)
(see p.5, No. 4)
Power Button allows users
to quickly turn on/o the
system.
Reset Button
(RSTBTN1)
(see p.5, No. 5)
Reset Button allows
users to quickly reset the
system.
