ASRock J3455 Pro BTC+ [21/52] English
![ASRock J3455 Pro BTC+ [21/52] English](/views2/1688617/page21/bg15.png)
16
English
Chassis Intrusion Header
(2-pin CI1)
(see p.5, No. 9)
is motherboard
supports CASE OPEN
detection feature that
detects if the chassis cove
has been removed. is
feature requires a chassis
with chassis intrusion
detection design.
Serial Port Header
(9-pin COM1)
(see p.5, No. 10)
is COM1 header
supports a serial port
module.
Mining Ports
(M_Port1: see p.5, No. 12)
(M_Port2: see p.5, No. 13)
(M_Port3: see p.5, No. 14)
Please connect these ports
to the riser kits.
CC T S #1
RR TS #1
DD S R #1
DD T R #1
RR X D 1
GN D
TT XD 1
DD C D #1
1
RR I # 1
1
Signal
GND
