7
English
J3455 Pro BTC+
1.4 I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB_1_2) 4 HDMI Port
2 LAN RJ-45 Port* 5 D-Sub Port
3 USB 3.1 Gen1 Ports (USB_3_4) 6 PS/2 Mouse/Keyboard Port
* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
1
5 36
2
4
