21
Resource Configuration:
PCI Latency Timer (PCI Clocks): The default is 32. It is recommended to
keep the default value unless the installed PCI expansion cards’
specifications require other settings.
Peripheral Configuration:
OnBoard FDC: Use this to enable or disable floppy drive controller. Select
[Auto] will enable this feature if the floppy drive controller is detected.
OnBoard Serial Port: Use this to set addresses for the onboard serial ports or
disable serial ports. Configuration options: [Auto], [Disabled], [3F8 / IRQ4 /
COM1], [2F8 / IRQ3 / COM2], [3E8 / IRQ4 / COM3], [2E8 / IRQ3 / COM4].
OnBoard Infrared Port: This allows you to enable or disable the onboard
infrared port feature. Select [Auto] will enable this feature if the infrared
module is installed.
AMIBIOS SETUP UTILITY - VERSION 3.31a
Advanced
OnBoard FDC
OnBoard Serial Port
OnBoard Infrared Port
OnBoard Parallel Port
Parallel Port Mode
EPP Version
Parallel Port IRQ
Parallel Port DMA Channel
OnBoard Midi Port
MIDI Port I/O Address
OnBoard Game Port
OnBoard IDE
OnBoard LAN
OnBoard AC' 97 Audio
OnBoard MC' 97 Modem
[ Setup Help ]
F1:Help
Esc:Previous Menu
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
Peripheral Configuration
Auto
Disabled
Auto
EPP+ECP
1.9
Auto
Auto
Enabled
330h - 333h
Both
Enabled
Enabled
Auto
Auto
Auto
<Enter> to enable or
disable the floppy
drive controller.
AMIBIOS SETUP UTILITY - VERSION 3.31a
Advanced
PCI Latency Timer (PCI Clocks)
[ Setup Help ]
F1:Help
Esc:Previous Menu
F9:Setup Defaults
F10:Save & Exit
+/-:Change Values
Enter:Select
Sub-Menu
:Select Item
Resource Configuration
32
<Enter> to select PCI
clocks. Leave on
default setting for the
best PCI performance.
