Audio: 2 channels AC’97 Audio
PCI LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN
Hardware Monitor: CPU temperature sensing (ASRock U-COP);
Chassis temperature sensing;
CPU overheat shutdown to protect CPU life (ASRock U-COP)
(see CAUTION 1);
Voltage monitoring: +12V, +5V, +3V, +2.5V, Vcore;
CPU fan tachometer; Chassis fan tachometer
PCI slots: 2 slots with PCI Specification 2.1
AMR slot: 1 slot, supports ASRock MR card (optional)
ASRock I/O
TM
: PS/2: 1 keyboard port / 1 mouse port;
1 RJ 45 port;
4 rear default USB 1.1 ports (see NOTE on page 7);
1 VGA port; 1 parallel port: ECP/EPP support;
Audio Jack: Line Out/ Line In/ Microphone + Game port
BIOS: AMI legal BIOS; Supports “Plug and Play”;
ACPI 1.1 compliance wake up events;
Supports jumperfree; SMBIOS 2.3.1 support;
CPU frequency stepless control
(only for advanced users’ reference, see CAUTION 2)
OS: Microsoft
®
Windows
®
98 SE / ME / 2000 / XP compliant
CAUTION!
1. While CPU overheat is detected, the system will automatically
shutdown. Please check if the CPU fan on the motherboard
functions properly before you resume the system. To improve heat
dissipation, remember to spray thermal grease between the CPU and
the heatsink when you install the PC system.
2. Although M810LMR offers stepless control, it is not recommended to
perform over clocking. When the CPU frequency of M810LMR is set
to perform over clocking, other clocks, such as PCI clock and Memory
clock will also be overclocked proportionally. Frequencies other than
the recommended CPU bus frequencies may cause the instability of
the system or damage the CPU and the motherboard.
