Chapter 2 Quick Installation
1. Connect USB Devices to the USB Ports.
2. Connect a VGA Monitor to the VGA Port.
4. Connect an HDMI Device to the HDMI Port.
3. Connect the Network with the RJ-45 LAN Port.
