ASRock Mini Series (Bay Trail-D) [18/70] Chapter 3 reinstalling the odd hdd
![ASRock Mini Series (Bay Trail-D) [18/70] Chapter 3 reinstalling the odd hdd](/views2/1692992/page18/bg12.png)
11
English
Mini Series
Chapter 3 Reinstalling the ODD/HDD
1. Remove the cover screws on the rear panel. (For safety reasons, please ensure that the
power cord is disconnected before opening the case.
2. Slide the side cover toward the rear panel and pull the side cover upwards.
3. To change the storage drives, you need to remove the SATA and power cables from the
ODD / HDD rst, then unscrew the screws from both sides.
