10
English
10. Connect Side Speakers. (Side Port for 4/6/8 Channel)
11. Connect an Optical Device to the Optical S/PDIF Out Port.
13. Power on the System.
14. Connect Headphones / Microphones / USB3.0 Devices
12. Connect Power to the DC-In Jack.
