ASRock Mini Series (Bay Trail-D) [20/70] Chapter 4 installing the second hdd
![ASRock Mini Series (Bay Trail-D) [20/70] Chapter 4 installing the second hdd](/views2/1692992/page20/bg14.png)
13
English
Mini Series
Chapter 4 Installing the second HDD
1. Please follow steps 1 to 4 above, and remove the ODD and the rst HDD in
advance. en fasten the screws of the second HDD to the rack.
2. Place the rst HDD to the rack and fasten the screws from both sides.
3. Place the ODD to the rack and fasten the screws from both sides.
Replace the rack to the chassis.
