Chapter 5 Dual Monitor
With the internal VGA output which supports DVI-D, HDMI and D-Sub, you can
enjoy dual monitor on your ASRock Mini series HTPC.
ASRock Mini series HTPC also provides independent display controllers for DVI-D,
HDMI and D-Sub to support dual VGA output so that DVI-D, HDMI and D-Sub
can drive the same or dierent display contents simultaneously.
To enable dual monitor, please connect monitor cables to the respective ports on the
I/O panel.
If you have already installed the VGA driver from our support CD to your system, you can
enjoy dual monitor aer your system reboots. If you haven’t installed the VGA driver yet,
please install the VGA driver from our support CD and restart your computer.
HDMI, DVI and D-Sub monitors cannot all be enabled at the same time. You can only
choose two of them.
