1.2 Specications
CPU
•
Intel® Quad-Core J1900 Processor
OS
•
Microso® Windows® 8.1 / 8.1 64-bit / 8 / 8 64-bit / 7 / 7 64-
bit compliant
Graphics
•
Integrated Intel® 7
th
generation graphics
Memory
•
4GB DDR3/DDR3L 1333MHz
•
Supports DDR3/DDR3L 1333/1066MHz
•
2 x SO-DIMM slots
•
Max. 16GB
HDD
•
500GB, Supports second 2.5" SATA3 HDD
ODD
•
DVD Super Multi
LAN
•
Gigabit LAN
Audio
•
7.1 CH HD Audio
WiFi + BT
•
WiFi 802.11 ac + BT v4.0
Front I/O
•
2 x USB 3.0
•
1 x MIC
•
1 x Headphone
Rear I/O
•
1 x HDMI
•
1 x DVI-D
•
1 x D-Sub
•
2 x USB 2.0
•
2 x USB 3.0
•
1 x S/PDIF
