2.3 Inside View
No. Description
1 M.2 WiFi Module (Optional)
2 mSATA Slot
3 SATA 3.0 Connector
4 SO-DIMM Slots
5 Clear CMOS Pad
*Clear CMOS Pad allows you to
clear the data in CMOS. To
clear CMOS, disconnect the
power supply and short the
Clear CMOS Pad.
6 Hard disk drive tray (compatible with 2.5" SATA HDD)
SO-DIMM memory, hard drive and mSATA SSD are not included with this system.
6
2
3
4
1
5
