D15XXD4U Series
28 29
English
Chassis ID0 Jumper
(3-pin CHASSIS_ID0)
(See p.6, 7, 10 or 13)
Chassis ID1 Jumper
(3-pin CHASSIS_ID1)
(See p.6, 7, 10 or 13)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(See p.6, 7, 10 or 13)
Board Level SKU (Default) For 3U8G system, passive
GPGPU
Chassis ID0 Jumper
(3-pin CHASSIS_ID0)
(See p.6, 7, 10 or 13)
Chassis ID1 Jumper
(3-pin CHASSIS_ID1)
(See p.6, 7, 10 or 13)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(See p.6, 7, 10 or 13)
For 3U8G system, active
GPGPU
Reserved for system level use
Chassis ID0 Jumper
(3-pin CHASSIS_ID0)
(See p.6, 7, 10 or 13)
Chassis ID1 Jumper
(3-pin CHASSIS_ID1)
(See p.6, 7, 10 or 13)
Chassis ID2 Jumper
(3-pin CHASSIS_ID2)
(See p.6, 7, 10 or 13)
Reserved for system level use Reserved for system level use
