D15XXD4U Series
2 3
English
D1541D4U-2O8R:
- 2 x 10G ber, SFP+ by CS4227
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
Management
BMC Controller ASPEED AST2400
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features
- Watch Dog
- NMI
- IPMI (Intelligent Platform Management Interface) v.2.0
- Virtual media over LAN function
- KVM over LAN function
Graphics
Controller ASPEED AST2400
VRAM DDR3 16MB SDRAM
Output Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
LAN Port
D1521D4U-2L+ / D1541D4U-2L+:
- RJ45: 2x GLAN(by Intel i350)
D1541D4U-2T8R:
- RJ45: 2x 10G-BaseT LAN(by Intel X540)
D1541D4U-2O8R:
- RJ45: 2x 10G SFP+ Optical Fiber (CS4227)
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID Button/UID
LED
1
Serial port COM x1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED, and system fault LED)
TPM Header 1
IPMB Header 1
COM Header 1
ME/SPS
Recovery
1
Buzzer 1
PWR_SMB 1
SGPIO 2
Smbus from
BMC
1
