1.2 Specications
D1521D4U-2L+ / D1541D4U-2L+ / D1541D4U-2O8R / D1541D4U-2T8R
MB Physical Status
Form Factor uATX
Dimension 9.6' x 9.6'' (24.4 cm x 24.4 cm)
Processor System
CPU D1521D4U-2L+:
Support Intel® Xeon® D1521 Processors
D1541D4U-2L+ / D1541D4U-2T8R / D1541D4U-2O8R:
Support Intel® Xeon® D1541 Processors
Chipset Soc
System Memory
Capacity - 4x DDR4 DIMM slots
- Supports up to 128GB DDR4 ECC RDIMM
- Supports up to 64GB DDR4 ECC/non-ECC UDIMM
DIMM Sizes and
Type per DIMM
- Non-ECC UDIMM :4GB, 8GB, 16GB
- ECC UDIMM : 4GB, 8GB, 16GB
- RDIMM : 4GB, 8GB, 16GB,32GB
Frequency D1521D4U-2L+:
- Non-ECC UDIMM : 1600, 1866, 2133MHz
- ECC UDIMM : 1600, 1866, 2133MHz
- RDIMM : 1600, 1866, 2133MHz
D1541D4U-2L+ / D1541D4U-2T8R / D1541D4U-2O8R:
- Non-ECC UDIMM : 1600, 1866, 2133MHz, 2400MHz
- ECC UDIMM : 1600, 1866, 2133MHz, 2400MHz
- RDIMM : 1600, 1866, 2133MHz, 2400MHz
Voltage 1.2V
Expansion Slot
PCIe 3.0 x16 D1521D4U-2L+ / D1541D4U-2L+:
1 slot (x16)
D1541D4U-2T8R / D1541D4U-2O8R:
1 slot (x8)
PCIe 3.0 x8 1 slot (x8)
Storage
SATA Controller D1541/D1521: 6 x SATA3 6Gb/s
Additional
Storage
Controller
- LSI3008 support 8 x SAS3 12Gbps by mini SAS HD
connector(switch with slot 7)
- Marvell 9172 for 2 ports to M.2
Ethernet
Interface 1000 /100 /10 Mbps
LAN Controller D1521D4U-2L+ / D1541D4U-2L+:
- 2 x RJ45 GLAN by Intel® i350
D1541D4U-2T8R:
- 2 x RJ45 GLAN by Intel® X540
