ASRock C3558D4I-4L [10/97] English
![ASRock C3558D4I-4L [10/97] English](/views2/1694343/page10/bga.png)
4 5
English
Fan
- CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU
Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
+BAT, 3VSB, 5VSB
Support OS
OS Microso®Windows®
- Server 2016 (64 bit)
- Server 2012 (64 bit)
- Server 2012 R2 (64 bit)
Linux
- RedHat Enterprise Linux Server 6.8 (32 / 64 bit) / 7.2 (64 bit)
- CentOS 6.8 (32 / 64 bit) / 7.2 (64 bit)
- SUSE Enterprise Linux Server 11 SP4 (32 / 64 bit) / 12 SP1
(64 bit)
- Fedora core 24 (64 bit)
- Ubuntu 16.04 (64 bit) / 15.10 (64 bit) (AHCI mode)
Virtual
- VMWare ESXi 6.0
* Please refer to our website for the latest OS support list.
Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
*Install a CPU Fan when the airow through the heatsink is below 2CFM.
* For detailed product information, please visit our website: http://www.asrockrack.com
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.
