Chapter 1 Introduction
ank you for purchasing ASRock Rack C3758D4I-4L / C3558D4I-4L motherboard,
a reliable motherboard produced under ASRock Rack’s consistently stringent quality
control. It delivers excellent performance with robust design conforming to ASRock
Rack’s commitment to quality and endurance.
In this manual, chapter 1 and 2 contains introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration
guide to BIOS setup and information of the Support CD.
1.1 Package Contents
•
ASRock Rack C3758D4I-4L / C3558D4I-4L Motherboard
(Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.02 cm x 17.02 cm)
•
Support CD
•
Quick Instllation Guide
•
1 x I/O Shield
•
2 x Mini SAS HD to 4 SAS/SATA Cables (12G)
•
2 x SATA3 Cables (6G) (60cm)
•
1 x SATA Power Cable (4PIN TO 15 PIN*6)
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/
