1.2 Specications
C3758D4I-4L / C3558D4I-4L
MB Physical Status
Form Factor Mini ITX
Dimension 6.7'' x 6.7'' (17.02 cm x 17.02 cm)
Processor System
CPU C3758D4I-4L:
Intel® Atom C3758 Series Processor: 8core, 25W
C3558D4I-4L:
Intel® Atom C3558 Series Processor: 4core, 16W
Chipset Soc
System Memory
Capacity - 4 x 288-pin DDR4 DIMM slots
- Support up to 128GB DDR4 RDIMM (32 GB w/8Gb DRAM)
- Support up to 64GB DDR4 UDIMM (16 GB w/8Gb DRAM)
DIMM Sizes and
Type per DIMM
- Dual Channel DDR4 memory technology
- Non-ECC, ECC UDIMM: 4GB, 8GB, 16GB
- RDIMM: 4GB, 8GB, 16GB, 32GB
Frequency - Non-ECC UDIMM: 1600/1866/2133/2400* MHz
- ECC UDIMM: 1600/1866/2133/2400* MHz
- RDIMM: 1600/1866/2133/2400* MHz
*Only C3758D4I-4L supports DDR4 up to 2400.
Voltage 1.2V
Expansion Slot
PCIe 3.0 x8
1 x PCIe MEx8 / EE x8 (MAX x8 by BIOS setup)
Storage
SATA Controller
C3758D4I-4L:
13 x SATA3 6.0 Gb/s: 5 x SATA3 ports (SATA_0, SATA_1,
SATA_2, SATA_3 and SATA_12) and 8 x SATA ports from 2
mini SAS HD connectors (SATA_4_7 and SATA_8_11)
C3558D4I-4L:
- 5 x SATA3 6.0 Gb/s: 5 x SATA3 ports (SATA_0, SATA_1,
SATA_2, SATA_3 and SATA_12)
- Supports up to 8 SATA ports from 2 mini SAS HD connectors
(SATA_4_7 and SATA_8_11) by BIOS setting (4 x SATA ports
from each mini SAS HD connector)
Ethernet
Interface Gigabit LAN 10/100/1000 Mb/s
LAN Controller - Marvell 88E1543(4L)
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 Supports NCSI
